• RISCO Bus detector with Anti-Cloak™ Technology.
• Up to 8.6m mounting height.
• 360° by 18m diameter coverage pattern.
• 3 independently adjustable PIR channels for customized coverage.
• RISCO Bus dramatically reduces cabling, installation equipment and labour costs, while providing benefits of remote services.
• Active IR Anti-Mask on all three channels.
• Built-in Triple EOL resistors, jumper selectable.
• Remote Control & Diagnostics via PC software or a bi-directional remote control.

Technical Specifications

• Coverage: 360° by 18m diameter: Coverage pattern consists of 192 fingers (96 Fresnel facets) divided into 3 lens sections. Each lens section has 4 vertical positions for variable mounting height and customized coverage.
• Variable Mounting Height: From 2.7m to 8.6m 4 lens positions according to installation height.
• Intruder Detection Method: Dual Technology (PIR MW) with Anti-Cloak™ Technology.
• Green Line Technology.
• Anti-Mask: 3 Active IR channels.
• Built-in EOL resistors: Triple EOL.
• True Temperature Compensation.
• Operating Voltage: 9 to 16 VDC.
• Current Consumption: 20mA at 12VDC, 30mA at 16 VDC.
• Maximum 40mA with all LEDs on.
• Optical Filtering for white light protection: PIR cover filter.
• RF immunity: 40 V/m from 10MHz to 1GHz.
• Operating Temperature: -20° C to 55° C.
• Storage Temperature: -20°C to 60° C.
• Dimensions: 99 x 194 mm.
